DHI-VTH1010J
|
|
System
|
|
Button Type
|
Touch button
|
|
Basic
|
|
Display
|
4.3" TFT
|
|
Screen Resolution
|
480 (H) × 272 (V)
|
|
Function
|
|
Communication Mode
|
Analog
|
|
Performance
|
|
Casing
|
ABS
|
|
General
|
|
Color
|
White
|
|
Power Supply
|
12 VDC 1 A
|
|
Power Adapter
|
Included
|
|
Installation
|
Surface mount
|
|
Certifications
|
CE/FCC
|
|
Accessory
|
Bracket (included)
|
|
Dimensions
|
136.00 mm × 140.00 mm × 18.30 mm (5.35" × 5.51" × 0.72")
|
|
Operating Temperature
|
–10 °C to +55 °C (+14 °F to +131 °F)
|
|
Operating Humidity
|
10%–95% (RH)
|
|
Power Consumption
|
≤ 2 W (standby)
≤ 5 W (working)
|
|
Net Weight
|
0.16 kg (0.35 lb)
|
|
Gross Weight
|
0.42 kg (0.96 lb)
|
|
DHI-VTO1000J
|
|
System
|
|
Button Type
|
Mechanical
|
|
Basic
|
|
Camera
|
1.3 MP CMOS
|
|
Field of View
|
Horizontal: 70°
Vertical: 40°
|
|
WDR
|
DWDR
|
|
Illuminator Type
|
Auto IR
|
|
Day/Night
|
ICR auto switch
|
|
Audio Input
|
1 channel to the microphone; pickup distance 0.5 m
|
|
Audio Output
|
1 channel to the speaker
|
|
Status Indicator
|
1 indicator light
Green: Power on
|
|
Function
|
|
Communication Method
|
Analog
|
|
Unlock Mode
|
Remote unlock
|
|
Performance
|
|
Casing
|
PC + ABS
|
|
Port
|
|
Exit Button
|
1
|
|
Door Status Detection
|
1
|
|
General
|
|
Color
|
Silver
|
|
Power Supply
|
Powered by indoor monitor
|
|
Installation
|
Surface mount
|
|
Certifications
|
CE/FCC
|
|
Accessory
|
Rain cover (included)
|
|
Dimensions
|
131.45 mm × 46.00 mm × 33.80 mm (5.18" × 1.81" × 1.33")
|
|
Protection Grade
|
IP66 (Apply silicon sealant to gaps between the device and the wall. Liquid sodium silicate is recommended. For details, see the quick start guide.)
|
|
Operating Temperature
|
–30 °C to +60 °C (–22 °F to +140 °F)
|
|
Operating Humidity
|
10%–95% (RH)
|
|
Power Consumption
|
≤ 1 W (standby)
≤ 3 W (working)
|
|
Net Weight
|
0.18 kg (0.40 lb)
|
|
Gross Weight
|
0.38 kg (0.84 lb)
|
