User Capacity
|
Hardware User: 1000, APP User: 100 (including 255 card/PIN users)
|
Common User
|
988
|
Visitor User
|
10
|
Panic User
|
2
|
PIN Length
|
4~6 digits
|
Operating Voltage
|
12V DC
|
Idle Current
|
≤ 60mA
|
Active Current
|
≤ 150mA
|
Proximity Card Reader
|
EM
|
Radio Technlogy
|
125KHz
|
Read Range
|
2~6cm
|
Wiring Connections
|
Relay output, exit button, alarm, door contact, Wiegand input/output
|
Relay
|
One (NO, NC, Common)
|
Adjustable Relay Output Time
|
0~99 Seconds (5 seconds default)
|
Lock Output Load
|
2 Amp Maximum
|
Wiegand Interface
|
EM card version: Wiegand 26~44 bits input & output (Factory default: Wiegand 26bits)
|
Mifare card version: Wiegand 26~44 bits, 56bits, 58bits input & output (Factory default: Wiegand 34bits)
|
PIN Output
|
4 bits, 8bits (ASCII), 10 digits Virtual Number (Factory default: 4bits)
|
Environment
|
Meets IP66
|
Operating Temperature
|
-40℃ ~ 60℃ (-40°F ~ 140°F)
|
Operating Humidity
|
0%RH ~ 98%RH
|
Physical
|
Zinc-Alloy
|
Color
|
Sliver & Black
|
Dimensions
|
L148 x W43.5 x H22 (mm)
|
