Camera
|
|
Image Sensor
|
1/3”4Megapixel progressive CMOS
|
|
Max. Resolution
|
2688 (H) ×1520 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
128 MB
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
Auto/Manual 1/3 s–1/100000 s
|
|
S/N Ratio
|
> 56 dB
|
|
Min. Illumination
|
0.03 Lux @ F2.0
|
|
Illumination Distance
|
30 m (98.4 ft)
|
|
Illuminator On/Off Control
|
Auto/Manual
|
|
Illuminator Number
|
1(IR LED)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–355°
Tilt: 0°–78°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Mount Type
|
M12
|
|
Focal Length
|
2.8 mm
3.6 mm
|
|
Max. Aperture
|
F2.0
|
|
Field of View
|
2.8 mm:
Horizontal: 93°
Vertical: 53°
Diagonal: 111°
3.6 mm:
Horizontal: 81°
Vertical: 44°
Diagonal: 95°
|
|
Iris Type
|
Fixed
|
|
Close Focus Distance
|
2.8 mm: 0.8 m (2.6 ft)
3.6 mm: 1.4 m (4.6 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8mm
|
50.0 m
(183.7 ft)
|
22.4 m
(73.5 ft)
|
11.2 m
(36.7 ft)
|
15.1 m
(18.4 ft)
|
|
3.6mm
|
80.0 m
(262.5 ft)
|
32.0 m
(105.0 ft)
|
16.0 m
(52.5 ft)
|
8.0 m
(26.2 ft)
|
|
Video
|
|
Video Compression
|
H.265; H.264; H.264B; MJPEG(only supported
by sub stream)
|
|
Smart Codec
|
Smart H.265+/ Smart H.264+
|
|
Video Frame Rate
|
Main Stream:
2688 × 1520 (1 fps–20 fps)
2560 × 1440 (1 fps–25/30 fps)
Sub Stream:
704 × 576 (1 fps–20/25 fps)
704 × 480 (1 fps–20/30 fps)
|
|
Stream Capability
|
2 streams
|
|
Resolution
|
2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 ×240)
|
|
Bit Rate Control
|
CBR; VBR
|
|
Video Bit Rate
|
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
|
|
Day/Night
|
Auto(ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
120 dB
|
|
White Balance
|
Auto/natural/street lamp/outdoor/manual/regional custom
|
|
Gain Control
|
Manual/Auto
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest(RoI)
|
Yes (4 areas)
|
|
Smart Illumination
|
Yes
|
|
Image Rotation
|
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower.)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
Alarm
|
|
Alarm Event
|
Network disconnection; IP conflict; motion detection; video tampering; illegal access; voltage detection; security exception
|
|
Network
|
|
Network
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Cyber Security
|
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
|
|
Protocol
|
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Bonjour
|
|
Interoperability
|
ONVIF (Profile S/Profile G/Profile T); CGI; Milestone; Genetec; P2P
|
|
User/Host
|
20
|
|
Storage
|
FTP; SFTP; NAS
|
|
Browser
|
IE
Chrome
Firefox
|
|
Management Software
|
Smart PSS; DSS; DMSS
|
|
Mobile Phone
|
IOS; Android
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
|
|
Power
|
|
Power Supply
|
12V DC/POE (802.3af)
|
|
Power Consumption
|
< 5.1W
|
|
Environment
|
|
Operating Conditions
|
-40°C to +55°C (-40°F to +131°F) /less than≤95%
|
|
Strorage Conditions
|
-40°C to +60°C (-40°F to +140°F)
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing
|
Inner core:metal+ plastic; cover:plastic
|
|
Dimensions
|
85.5 mm × Φ109 mm (3.4" × Φ4.3")
|
|
Net Weight
|
0.25 kg (0.6 lb)
|
|
Gross Weight
|
0.37 kg (0.8 lb)
|
