| Standard&Protocol |
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Ethernet Interface |
10/100/1000Mbps WAN port*1 10/100/1000Mbps LAN port*1 |
| Antenna |
2 x 3dBi Internal antenna |
| Button |
1 x Reset Button 1 x MESH Button |
| Power |
Input: AC 100-240V~50/60Hz Output:DC 12V⎓1A |
| Dimension |
90*90*93 mm (3.54*3.54*3.65 in.) |
| LED Indicator |
SYS*1 |
| Wireless Standard |
2.4GHz:IEEE 802.11n/b/g 5GHz:IEEE 802.11ax/ac/n/a |
| Wireless roaming |
Comply with IEEE802.11k/v |
| Mesh network Standard |
Tenda EasyMesh |
| Rate |
5GHz:1201Mbps 2.4GHz:300Mbps |
| Frequency |
2.4GHz & 5GHz |
| Transmission Power |
CE: <20dBm(2.4GHz) <23dBm(5GHz) FCC: <30dBm(2.4GHz) <30dBm(5GHz) |
| Basic Features |
OFDMA MU-MIMO Beamforming |
| Wireless Security |
WPA2-PSK WPA3-SAE/WPA2-PSK Wireless Encryption Disable and Enable WPS Fast Connection |
| Operating Mode |
Router Mode,AP Mode |
| Internet Connection Type |
PPPoE, Dynamic IP, Static IP PPPoE(Russia), PPTP(Russia), L2TP(Russia) Unify,Maxis,Maxis-special,Celcom,Digi |
| DHCP Server |
DHCP Server DHCP Client List DHCP Reservation |
| Virtual Server |
Port Forwarding DMZ Host UPnP |
| Parental Control |
URL Filter Time Limit |
| Firewall |
Forbid UDP Flood Attack Forbid TCP Flood Attack Forbid ICMP Flood Attack Forbid WAN Ping from Internet |
| VPN |
IPsec Pass Through PPTP Pass Through L2TP Pass Through PPTP VPN Server PPTP VPN Client L2TP VPN Client |
| DNS |
Support DynDNS, No-ip |
| Special Features |
WPA3 TR069 Tenda EasyMesh Unify 2.4 GHz & 5 GHz Smart LED on/off Amazon Alexa One-button Fault Diagnosis Broadband Account Migration Tenda App: Local and Remote ManagementSpeed Test Monthly Report |
| Others |
IPTV IPv6 Guest Network System Log Remote Web Management MAC Clone Backup & Restore configurations Support automatic access detection Firmware upgrade online |
| Operation Temperature |
0 ~ 40 ℃ |
| Storage Temperature |
-40 ~ 70 ℃ |
| Operating Humidity |
10%~90% RH non-condensing |
| Storage Humidity |
5%~90% RH non-condensing |
| APP installation |
Available in iOS 8.0 or later, Android 4.0 or later |
| Certification |
CE FCC RoHS |
