XVR308-32Q3
|
|
Video/Audio Input
|
|
IP Video Input
|
4-ch
|
|
Analog Video Input
|
32-ch, BNC
|
|
Max IP Video Input
|
36-ch
|
|
Supported Analog Camera Types
|
Support AHD input:
8MP@15fps
5MP@20fps
4MP@30fps
1080P@30fps
720P@30fps
Support TVI input:
8MP@15fps
5MP@20fps
4MP@30fps
1080P@30fps
720P@30fps
Support CVI input:
8MP@15fps
5MP@25fps
4MP@30fps
1080P@30fps
720P@30fps
Support CVBS input
|
|
BNC Audio Input
|
32-ch, channel audio
|
|
RCA Audio Input
|
1-ch
|
|
Video/Audio Output
|
|
HDMI Output
|
HDMI1: 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz; HDMI2: 4K (3840 × 2160)/30 Hz, 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
|
|
VGA Output
|
VGA: 1920 × 1080/60 Hz, 1920 × 1080/50 Hz, 1600 × 1200/60 Hz, 1280 × 1024/60 Hz, 1280 × 720/60 Hz, 1024 × 768/60 Hz
|
|
BNC Video Output
|
1-ch
|
|
RCA Audio Output
|
1-ch
|
|
Live View Display
|
HDMI/VGA: 1/4/6/8/9/16/25/36
|
|
Playback Screen
|
1/4/9/16
|
|
Encoding/Decoding
|
|
Recording Resolution
|
8MP Lite/5MP Lite/4MP Lite /1080P/720P/D1
|
|
Recording Frame Rate
|
Main stream: 8MP Lite@8fps
Sub stream: D1@8fps
Main stream: 5MP Lite@12fps
Sub stream: D1@12fps
Main stream: 4MP Lite@15fps
Sub stream: D1@15fps
Main stream: 1080P@15fps
Sub stream: D1@15fps
Main stream: 720P@30fps
Sub stream: D1@30fps
|
|
Audio Sample Rate
|
8 kHz, 16 bit per channel
|
|
Audio Bit Rate
|
64 Kbps per channel
|
|
Decoding Capability
|
Analog: 32 x 8MP Lite@8, 32 x 5MP Lite@12, 32 x 4MP Lite@15, 32 x 1080P@25, 32 x 720@30
IP: 2 x 8MP@30, 4 x 4MP@30, 8 x 1080P@30, 16 x 720P@30, 36 x D1, 16 x 720P@30
|
|
Num of Concurrent Playback in Local
|
16-ch
|
|
Coaxial Cable
|
|
Audio over Coaxial Cable(Form)
|
32-ch, One-way Audio(TVI&Uniview CVI protocol cameras)
|
|
Two-way Audio
|
|
Two-way Audio
|
1-ch, RCA (Using the audio input and output)
|
|
Analog Snapshot
|
|
FTP/Schedule/Event Snapshot
|
Schedule/FTP/Event snapshot:32-ch snapshot, up to 704*576 resolution
|
|
Network
|
|
Incoming Bandwidth
|
160Mbps (Up to 224 Mbps after all analog channel conversion)
|
|
Outgoing Bandwidth
|
160Mbps
|
|
Remote Users
|
128
|
|
Protocols
|
TCP/IP, P2P, UPnP, DHCP, HTTP, HTTPS, DNS, DDNS, SMTP, IPv6
|
|
Browser(Plugin)
|
IE10, IE11, Chrome 45+, Edge 79+, Firefox 52+
|
|
|
|
